Vgate iCar Pro V2.2 OBDII BLE 4.0 Bluetooth Diagnostic Scanner with Full Protocol Coverage for Android and iOS

The Vgate iCar Pro V2.2 is an automotive scanning tool that connects to your vehicle's OBDII port to read and clear diagnostic trouble codes. Supporting all standard OBD-II protocols including CAN, KWP, and J1850, this device works with a wide range of vehicles from 1996 onwards. The built-in database contains over 3000 generic code definitions, so you can understand what triggers the check engine light without needing a workshop manual. Real-time data streams include engine RPM, coolant temperature, vehicle speed, intake air temperature, fuel pressure, and oxygen sensor readings. Connectivity options cover Bluetooth 3.0, Bluetooth 4.0 BLE, and WIFI, making it compatible with both Android and iOS devices.

Features and Construction

The Vgate iCar Pro V2.2 is built around hardware version 2.2 with robust electronics designed for automotive diagnostics. Its OBDII connector fits all standard ports, and the device draws under 200mA during operation.

Protocol Support and Compatibility

This scanner supports all OBD-II protocols: SAE J1850 PWM (41.6 Kbaud), SAE J1850 VPW (10.4 Kbaud), ISO9141-2, ISO14230-4 KWP (5 baud init and fast init), ISO15765-4 CAN (11bit and 29bit ID at 500 and 250 Kbaud), SAE J1939 CAN (29bit ID at 250 Kbaud), plus user-configurable CAN protocols at 125 and 50 Kbaud. Many parameters are user-adjustable via default settings.

Connection Methods

The device offers three connection methods: Bluetooth 3.0, Bluetooth 4.0 BLE, and WIFI. Bluetooth 4.0 is recommended for direct pairing within the diagnostic app on both Android and iOS. Bluetooth 3.0 is suitable for older Android devices, while WIFI provides an alternative stable connection for either platform.

Size and Practical Fit

The device operates within a supply voltage of 11.5V to 15V and draws less than 200mA during active use. Standby current is under 30mA. It functions across a wide temperature range from -40°C to 85°C and withstands humidity up to 95% RH non-dewfall, making it suitable for use in various climates.

Uses and Placement

The Vgate iCar Pro is intended for DIY diagnostics, routine vehicle checks, and professional troubleshooting. It connects to the OBDII port located under the dashboard of most vehicles.

Diagnostic and Troubleshooting

Read and clear both generic and manufacturer-specific trouble codes. The database explains over 3000 generic codes, helping you identify issues related to fuel systems, emissions, ignition, and sensors. Real-time data includes engine RPM, calculated load value, coolant temperature, fuel system status, vehicle speed, short and long term fuel trim, intake manifold pressure, timing advance, intake air temperature, air flow rate, absolute throttle position, and oxygen sensor voltages with associated short term fuel trims.

Monitor Vehicle Performance

Use the scanner to monitor live engine parameters during test drives. Check fuel pressure, fuel system status, and oxygen sensor activity to assess combustion efficiency. The data stream helps detect intermittent faults that may not store a trouble code.

Everyday Home Use

Regularly scanning your vehicle can help catch minor issues before they become major repairs. The simple Bluetooth or WIFI connection means you can use a smartphone or tablet as the display unit without needing a separate laptop.

Benefits and Buying Value

This OBDII scanner offers a cost-effective way to understand your vehicle's health without relying on a garage for every check engine light.

Reuse and Low Maintenance

The device requires no consumables and works across multiple vehicles. Its low standby current ensures minimal battery drain when left connected. The wide operating temperature range and humidity tolerance mean it can be stored in a glove box year-round.

Why Choose This Product

The Vgate iCar Pro V2.2 provides full OBD-II protocol support with three wireless connection options. The hardware version 2.2 ensures reliable communication, and the built-in code database saves time interpreting fault codes. Compatibility with both Android and iOS makes it a versatile tool for any driver or mechanic.
